Gibraltar BSNYLA34-G Studded Pivotal Leveling Mount 5000 Lb

Product Description

The GIBRALTAR BSNYLA34-G is a studded pivotal leveling mount designed to provide stable, adjustable support for industrial equipment, machinery bases, and fabricated frames. The pivoting stud head allows for angular compensation on uneven surfaces, keeping equipment level without shimming. Built with a stainless steel pad and stainless steel stud, this mount handles demanding environments where corrosion resistance is required. It carries a 5,000 lb load capacity and features a 3-inch base diameter with a 3/8-16 bolt thread size. Installers in industrial maintenance, equipment installation, and mechanical contracting use this type of mount during machinery setup and alignment.

This leveling mount is suited for use under machine bases, workbenches, production equipment, and fabricated steel frames in both light industrial and heavy-duty commercial applications. The 5-inch overall length provides a usable adjustment range for leveling across floor surfaces that are not perfectly flat. The stainless steel construction makes it a practical choice in wet, wash-down, or corrosive environments such as food processing, chemical handling, or outdoor installations.

Key Features

• 5,000 lb rated load capacity for heavy-duty equipment support
• Pivotal stud head compensates for angular misalignment on uneven floors
• Stainless steel pad and stud resist corrosion in wet or harsh environments
• 3-inch base diameter provides a stable footprint
• 3/8-16 bolt thread for straightforward installation into tapped equipment bases
• 5-inch length offers meaningful vertical adjustment range

Compatibility

Designed as an OEM-style replacement or upgrade leveling foot for industrial machinery, fabricated equipment frames, and mechanical bases that accept a 3/8-16 threaded stud mount.

Installation Notes

Installation is typically performed by millwrights, mechanical contractors, or industrial maintenance technicians. Thread the stud into the tapped hole of the equipment base and use a wrench or socket to tighten while achieving the desired height adjustment. Ensure the equipment is de-energized and supported safely before adjusting leveling mounts under load. Always verify that the floor surface load rating is adequate for the combined equipment and mount load before final installation.
