Gibraltar BSMNYLD34-G Studded Pivotal Leveling Mount M20

Product Description

The GIBRALTAR BSMNYLD34-G is a studded pivotal leveling mount designed for industrial and commercial equipment positioning applications. It features a stainless steel pad and stainless steel stud, delivering corrosion resistance in demanding environments. The mount has a load capacity of 2,270 kilograms and a base diameter of 76 millimeters, making it well-suited for supporting heavy machinery, frames, or fabricated assemblies. The pivotal pad design allows for minor angular adjustments to compensate for uneven floors or mounting surfaces. Millwrights, maintenance technicians, and industrial installers work with this type of hardware during equipment installation and leveling procedures.

This leveling mount is used in industrial facilities, manufacturing plants, and commercial settings where heavy equipment requires precise floor-level adjustment. The M20 threaded stud interfaces with standard M20 tapped holes in equipment bases or frames. The 130-millimeter overall length provides meaningful height adjustment range for shimming and leveling tasks. Typical applications include machinery bases, conveyor supports, workstation frames, and fabricated steel structures where a stable, adjustable footing is required.

Key Features

• Stainless steel pad and stud construction for corrosion resistance in wet or harsh environments
• 2,270 kilogram load capacity supports heavy industrial equipment
• Pivotal pad design compensates for minor surface irregularities and angular misalignment
• M20 threaded stud for compatibility with standard metric tapped mounting holes
• 76 millimeter base diameter distributes load across the contact surface
• 130 millimeter overall length provides height adjustment clearance

Compatibility

Designed as an OEM-style replacement or direct-fit leveling mount for industrial equipment bases and frames using M20 threaded mounting points.

Installation Notes

Installation is typically performed by millwrights or maintenance technicians using standard metric hand tools. Before installation, ensure the equipment is de-energized and any hydraulic or pneumatic systems are depressurized. Thread the stud fully into the equipment base mounting hole and adjust the mount height before applying final load. Check floor contact and level the equipment with a precision level before locking the mount in position.
