Gibraltar BNYLB36-EL-G Studded Pivotal Leveling Mount

Product Description

The GIBRALTAR BNYLB36-EL-G is a studded pivotal leveling mount designed to support and stabilize industrial machinery, equipment frames, and fabricated structures. The mount features a steel stud threaded at 1/2-13 and a 3-inch diameter elastomer pad base that absorbs vibration and allows minor angular adjustment to compensate for uneven floors. Rated at 5,000 lb load capacity with an overall length of 7 inches, this leveling mount is built for demanding shop-floor and production environments where precise leveling and load distribution are required. Licensed tradespeople and millwrights install these mounts during machinery positioning and alignment work.

This leveling mount is suited for use in manufacturing facilities, machine shops, and industrial maintenance applications. It is typically installed at the base feet of heavy equipment, workbenches, conveyors, and fabricated steel frames. The elastomer pad reduces vibration transmission to the floor and provides a non-slip interface on concrete or steel surfaces. The pivotal design accommodates slight surface irregularities without requiring shimming, making it a practical choice for initial installation or equipment repositioning in production and maintenance environments.

Key Features

• 5,000 lb rated load capacity for heavy industrial equipment support
• 1/2-13 threaded steel stud for secure mounting into tapped equipment feet
• 3-inch diameter base provides stable footprint and load distribution
• Elastomer pad absorbs vibration and protects floor surfaces
• Pivotal base design compensates for minor floor irregularities without shimming
• 7-inch overall length allows height adjustment range during leveling

Compatibility

Designed as an OEM-style replacement or aftermarket leveling foot for industrial machinery, fabricated equipment frames, and heavy workbenches that use a 1/2-13 threaded mounting stud.

Installation Notes

Installation is typically performed by millwrights or maintenance mechanics during machinery placement or realignment. Thread the stud into the equipment base foot and adjust height before tightening the jam nut to lock the leveling position. Ensure the mating thread in the equipment base is clean and free of debris before installation. Always verify that the total combined load across all mount points does not exceed the rated capacity per mount.
