Gibraltar BNYLB34-G Studded Pivotal Leveling Mount 5000 Lb

Product Description

The GIBRALTAR BNYLB34-G is a studded pivotal leveling mount designed for heavy-duty industrial and commercial equipment support applications. It features a steel pad and steel stud construction, providing a 5,000 lb load capacity with a 3-inch base diameter. The pivoting design allows the mount to compensate for uneven or angled surfaces, maintaining stable, level support under load. At 0.4 pounds, it is a compact yet robust component. Licensed millwrights, maintenance technicians, and equipment installers use this mount to level machinery, workstations, frames, and structural supports on shop floors and production environments.

This leveling mount is suited for use in industrial facilities, commercial shops, and manufacturing environments where equipment must be precisely leveled on concrete or metal flooring. The 1/2-13 bolt thread size makes it compatible with standard threaded mounting holes found on machine bases, equipment frames, and fabricated steel structures. It is appropriate for applications requiring a rigid, adjustable footing under static or low-vibration loads up to 5,000 lb.

Key Features

• 5,000 lb load capacity for heavy equipment support
• Pivotal design compensates for uneven or angled mounting surfaces
• Steel pad and steel stud construction for durability in industrial environments
• 3-inch base diameter provides stable footprint
• 1/2-13 bolt thread size fits standard machine base mounting holes
• 5-inch overall length allows for leveling adjustment range

Compatibility

Designed as an OEM-style replacement or new-installation leveling mount for equipment frames and machine bases using 1/2-13 threaded mounting points.

Installation Notes

Installation is performed by millwrights, maintenance mechanics, or equipment installers. De-energize and fully support the equipment before installing or adjusting leveling mounts. Use appropriate hand tools to thread the stud into the equipment base and adjust height as needed to achieve level. Verify that the load does not exceed the rated 5,000 lb capacity per mount point.
