Gibraltar BMNYLD34-G Studded Pivotal Leveling Mount M20

Product Description

The GIBRALTAR BMNYLD34-G is a studded pivotal leveling mount designed to support heavy equipment loads while allowing angular adjustment during installation. The mount features a steel pad base with a 76 mm base diameter and a steel stud with M20 bolt thread sizing. With a rated load capacity of 2,270 kg, it is built for industrial and commercial equipment positioning applications. Licensed millwrights, maintenance mechanics, and industrial installers use this type of component to set precise equipment elevation and compensate for uneven floor surfaces. The overall length is 130 mm, making it a compact yet high-capacity leveling solution.

This leveling mount is suited for use in industrial facilities, manufacturing environments, and commercial mechanical rooms where machinery, frames, or equipment bases require stable, adjustable floor contact points. The pivotal pad design accommodates slight angular misalignment between the stud axis and the floor surface, reducing stress concentrations at the contact point. It is typically installed on equipment skids, machine bases, conveyor frames, and similar structural assemblies that require post-installation height and level adjustment.

Key Features

• 2,270 kg load capacity for heavy equipment support applications
• Pivotal steel pad compensates for angular floor surface variations
• M20 bolt thread size for compatibility with standard metric fastener systems
• 76 mm base diameter provides stable floor contact footprint
• 130 mm overall length suits standard equipment base leveling requirements
• All-steel construction for durability in industrial environments

Compatibility

Designed as an OEM-style replacement or direct-install leveling mount for industrial equipment bases, machine frames, and structural skids requiring M20 studded pivotal leveling hardware.

Installation Notes

Installation is typically performed by millwrights or qualified maintenance personnel familiar with industrial equipment alignment procedures. Before installing or adjusting leveling mounts, ensure the equipment is de-energized, depressurized, and safely supported. Use appropriate torque tooling for M20 fasteners per the equipment manufacturer's specifications. Verify final equipment level with a precision level instrument before returning machinery to service.
