Gibraltar 8E-SS Mach.-g Rod End 7/8-9 Unc Stainless Steel

Product Description

The GIBRALTAR 8E-SS MACH.-G is a male-threaded rod end designed for mechanical linkage, industrial actuator, and motion-control applications where corrosion resistance is critical. It features a 7/8-9 UNC external male thread and a 7/8-inch shank diameter. The eye hole head provides a pivot point for connecting rods, tie bars, and control linkages. Constructed from Grade 304 stainless steel throughout, this rod end resists rust and chemical exposure in wet or outdoor environments. Machinists, millwrights, and industrial maintenance technicians install this hardware in equipment requiring reliable articulating connections under load.

This rod end fits residential and commercial mechanical systems where an articulating male-threaded clevis or pivot point is needed. Common applications include HVAC damper linkages, valve actuator connections, and general industrial machinery. The 7/8-9 UNC thread standard ensures compatibility with standard inch-system hardware and rod ends in the same thread family. The 6-inch hole-center-to-end measurement provides adequate reach for most standard linkage configurations without additional extension hardware.

Key Features

• Grade 304 stainless steel construction resists corrosion in wet, outdoor, and chemical-exposure environments
• 7/8-9 UNC external male thread for compatibility with standard inch-system hardware
• Eye hole head provides a clean pivot point for linkage and actuator connections
• 7/8-inch shank diameter and 1-13/16-inch head outside diameter suit heavy-duty linkage applications
• 6-inch hole-center-to-end length accommodates standard reach requirements without extension
• 7/8-inch head thickness provides structural depth at the pivot interface

Compatibility

Designed as a standard inch-system male-threaded rod end for use in mechanical linkage assemblies requiring a 7/8-9 UNC thread and Grade 304 stainless steel construction.

Installation Notes

Installation is performed by machinists, millwrights, or qualified maintenance technicians. De-energize and lock out all mechanical and electrical systems before removing or installing linkage hardware. Thread the rod end onto the mating component by hand first to confirm thread engagement before applying a wrench, and use a jam nut on the threaded shank to secure position and prevent loosening under vibration. Do not exceed the rated load capacity of the pivot pin or mating hardware used through the eye hole.
