Gibraltar 26405 1 Fixed Lifting Eye Bolt 2000 Lb 7/16-14

Product Description

The GIBRALTAR 26405 1 is a fixed lifting eye bolt with shoulder, designed for overhead lifting and rigging applications in industrial and construction environments. Built from C-1035 grade steel with a hot dipped galvanized finish, it delivers a rated lifting capacity of 2,000 pounds. The shank measures 2 inches in length with a fully threaded 7/16-14 thread, allowing secure fastening through structural members or lifting points. The shoulder design seats flush against the mounting surface to resist lateral loading and maintain alignment under load. This part is installed by riggers, millwrights, and maintenance professionals who require a reliable, corrosion-resistant anchor point for vertical lifts.

This eye bolt is suited for fixed lifting point installations in industrial facilities, manufacturing plants, warehouses, and construction job sites. The hot dipped galvanized finish makes it appropriate for outdoor or moderately corrosive environments. It is used wherever a permanent or semi-permanent overhead lift attachment is needed, including machinery installation, material handling systems, and structural rigging setups. The with-shoulder design is specifically intended for in-line, vertical lifting loads.

Key Features

• 2,000 lb rated lifting capacity for dependable overhead rigging
• Fixed eye with shoulder for flush surface seating and in-line load alignment
• Fully threaded 2-inch shank with 7/16-14 thread for secure engagement
• C-1035 grade steel construction for strength and durability
• Hot dipped galvanized finish for corrosion resistance in outdoor or damp environments
• Eye inside diameter of 1-3/32 inches accommodates standard shackles and hooks

Compatibility

Designed as a standard fixed shoulder lifting eye bolt for use in rigging and material handling applications requiring a 7/16-14 threaded anchor point with a 2,000 lb load rating.

Installation Notes

Installation should be performed by qualified rigging or maintenance personnel following applicable ASME B30.26 rigging hardware standards. The eye bolt must be fully threaded into a tapped hole or used with a nut and washer against a structural surface, with the shoulder seated fully flush before applying any load. Never side-load a fixed lifting eye bolt — the rated capacity applies to in-line, vertical lifting only. Inspect the eye bolt and mating hardware for damage or corrosion before each use.
