Gibraltar 12908 4 Fixed Lifting Eye Bolt 3200 Lb 9/16-12

Product Description

The GIBRALTAR 12908 4 is a fixed lifting eye bolt designed for overhead rigging and load-lifting applications in industrial and construction environments. Built from Grade C-1035 forged steel, this shoulder-style eye bolt carries a rated lifting capacity of 3,200 pounds and features a fully threaded 9/16-12 shank. The shank length is 2 inches with a thread length of 2 inches. The forged steel construction delivers the strength and consistency required for repeated lifting cycles. Licensed riggers, millwrights, and mechanical contractors are the primary installers for this type of hardware.

This eye bolt is suited for use in residential, commercial, and industrial lifting setups where a fixed anchor point is required. The shoulder design distributes load at the mounting surface, making it appropriate for applications where angular loading may be a concern. Common uses include securing rigging hardware to structural steel, machinery, concrete inserts, and equipment frames. The 1-9/32-inch inside eye diameter accommodates standard shackles and hooks used in typical rigging assemblies.

Key Features

• 3,200 lb rated lifting capacity for demanding overhead load applications
• Grade C-1035 forged steel construction for strength and durability
• Shoulder-style base (9/16-inch shoulder diameter) distributes load at the mounting surface
• Fully threaded 9/16-12 shank with 2-inch thread length and 2-inch shank length
• 1-9/32-inch inside eye diameter accommodates standard rigging hooks and shackles
• 2-9/32-inch outside eye diameter

Compatibility

Designed as a fixed shoulder eye bolt for use with standard 9/16-12 threaded inserts, nuts, and tapped holes in structural and equipment applications where a rated lifting anchor point is required.

Installation Notes

Installation should be performed by a qualified rigger or mechanical contractor familiar with applicable ASME B30 rigging standards. Ensure the mating thread is clean and the eye bolt is fully seated against the shoulder before loading. Always de-rate lifting capacity for angular loads in accordance with the applicable load chart. Do not use a damaged or deformed eye bolt for lifting.
