Georg Fischer 9835-060N Cpvc Sch 80 6 in Female Adapter

Product Description

The GEORG FISCHER 9835-060N is a Schedule 80 CPVC female adapter designed to transition a 6-inch socket connection on one end to a 6-inch female NPT threaded connection on the other. Rated to 150 psi maximum working pressure and capable of handling temperatures from 32 degrees F to 176 degrees F at rated pressure, this adapter is built for demanding industrial and commercial piping systems where chemical resistance and pressure integrity are required. Licensed plumbers and pipefitters install this fitting in systems conveying corrosive fluids, hot water, or chemicals where metal fittings are not suitable. It meets ASTM F439 and is NSF 61 certified for low-lead compliance.

This adapter is suited for commercial and industrial plumbing, chemical processing lines, and water treatment applications using Schedule 80 CPVC pipe at 6-inch nominal pipe size. It is appropriate where a socket-welded CPVC line must connect to an NPT-threaded component such as a valve, pump, or equipment fitting. The gray CPVC construction provides good resistance to a broad range of chemicals and elevated temperatures encountered in process piping environments.

Key Features

• Schedule 80 CPVC construction rated to 150 psi maximum pressure
• 6-inch socket (Side A) to 6-inch female NPT (Side B) transition
• Max operating temperature of 176 degrees F at rated pressure
• NSF 61 certified for low-lead compliance in potable water systems
• Meets ASTM F439 standard for CPVC socket-type fittings
• RoHS compliant per supplier documentation

Compatibility

Designed as an OEM-style replacement or new-installation fitting for Schedule 80 CPVC piping systems at 6-inch nominal pipe size conforming to ASTM F439.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and ASTM F439 guidelines. Shut down and depressurize the system completely before cutting into any existing line. Use approved CPVC solvent cement on the socket end and appropriate PTFE tape or pipe thread sealant on the NPT end. Do not apply solvent cement to the threaded side, and do not overtighten threaded connections, which can crack CPVC fittings.

Technical Specifications

• Body Material: CPVC
• Color: Gray
• Pipe Size: 6 inches nominal
• Schedule: 80
• Connection Side A: Socket, Female, 6 inches nominal, 7.5 inches outside diameter
• Connection Side B: NPT, Female, 6 inches nominal, 7.5 inches outside diameter, 8 threads per inch
• Overall Length: 7.5 inches
• Max Pressure: 150 psi
• Max Operating Pressure: 140 psi at 73 degrees F
• Temperature Range: 32 degrees F to 200 degrees F
• Max Operating Temperature: 176 degrees F
• Standards: ASTM F439
• Certifications: NSF 61, RoHS
• Included Plug: No
• Included Pre-applied Thread Sealant: No
• Included Seals: No

Standard Information

• Brand: GEORG FISCHER
• Manufacturer Part Number: 9835-060N
