Georg Fischer 163546347 Ball Valve 546 CPVC 2 Inch

Product Description

The GEORG FISCHER 163546347 Ball Valve 546 CPVC is a 2-inch true union valve designed for diverse industrial applications. Constructed from CPVC with EPDM seals, it offers chemical resistance and is suitable for Schedule 80 pipe systems. This manual ball valve features a socket/threaded NPT connection, a breakaway stem, and can be actuated. It is ideal for chemical, swimming pool, aquarium, and wastewater systems.

• True Union design for easy installation and maintenance.
• CPVC construction with EPDM seals for chemical resistance.
• Socket/Threaded NPT connection for versatile piping systems.

Product Highlights

Durable CPVC ball valve with EPDM seals, suitable for corrosive chemical, pool, and wastewater applications.

Product Information

Standard Information

• Brand: GEORG FISCHER
• Manufacturer Part Number: 163546347

Technical Specifications

• MPN: 163546347
• Brand: Georg Fischer
• Product Type: Ball Valve
• Series: 546
• Body Material: CPVC
• Ball Material: CPVC
• Stem Material: CPVC
• Size: 2 Inch
• Connection Type: Socket/Threaded NPT True Union
• Seal Material: EPDM
• Body Style: Inline True Union
• Valve Structure: 2-Piece
• Port: Full
• Max. Pressure: 150 psi CWP
• Max. Steam Pressure: 0 psi WSP
• Temperature Range: 32 Degrees to 176 Degrees F
• Seat Material: PTFE
• Stem Type: Blowout Proof
• Handle Type: Tee
• Handle Material: Glass Filled Polypropylene
• Product Group: Manual
• Basic Body Material: Plastic
• Standards: ASTM 1970-01, ASTM D1784, FDA, NSF 61, USP Class VI
• Overall Length: 7.2 in
