Genteq Y429BS Blower Motor 1/3 HP (48-frame)

Product Description

The Genteq Y429BS blower motor is a 1/3 HP, 115 V multi-speed direct-drive unit for residential and light commercial HVAC systems. It delivers 1075 RPM in a 48-frame housing with a 1/2 in shaft and ball bearings. The PSC split-capacitor design requires an external capacitor (15 uF / 370 V), includes thermal protection, reversible CW/CCW rotation, and multiple colored lead wires for connections.

• 1/3 HP, 1075 RPM multi-speed direct-drive motor; 115 V, single-phase operation
• 48-frame housing with 1/2 in shaft, ball bearings, and reversible CW/CCW rotation
• PSC (split-capacitor) design requiring external capacitor (15 uF / 370 V); thermally protected; multiple colored wires

Product Highlights

Multi-speed PSC blower motor for residential and light commercial HVAC applications; 48-frame, 1/2 in shaft, thermal protection

Product Information

Standard Information

• Brand: GENTEQ
• Manufacturer Part Number: Y429BS

Technical Specifications

• Brand: GENTEQ
• Model: Y429BS
• MPN: Y429BS
• Power: 1/3 HP
• Speed: 1075 RPM
• Input Voltage: 115 V, single-phase
• Frame Size: 48-frame
• Shaft Diameter: 1/2 in
• Bearings: Ball bearings
• Rotation: Reversible (CW/CCW)
• Motor Type: Multi-speed direct drive, PSC (split-capacitor) design
• Capacitor Required: Yes
• Capacitor Rating: 15 uF / 370 V
• Thermal Protection: Yes
• Wiring: Multiple colored lead wires
• Application: Residential and light commercial HVAC systems; air conditioner blower, air handlers, furnaces, fan coil units
• CPN: 51-101728-04
