Genteq Motors H130C-F condenser fan motor 1/2 1/4 Hp

Product Description

The GENTEQ MOTORS H130C-F is a condenser fan motor built for air-over applications. This unit features a permanent split capacitor design and offers thermal protection for safe operation.

• Condenser fan motor with permanent split capacitor (PSC) design
• Features thermal protection and ball bearings
• Operates at two speeds and is reversible

Product Highlights

The H130C-F is ideal for HVAC installations where reliable performance is needed. It has a robust construction with extended studs for easy mounting and operates at two different speeds for versatility in cooling applications.

Product Information

Standard Information

• Brand: GENTEQ MOTORS
• MPN: H130C-F

Technical Specifications

• Thermal Protection: Automatic
• Speed: 1075 rpm
• Current: 3.6, 1.7 A
• Number of Speeds: 2
• Ambient Temperature: 70 °C
• Weight: 17.00 LB
• Power Output: 1/2, 1/4 Hp
• Frame: 48Y
• Enclosure: Totally Enclosed
• Electrical Type: Permanent Split Capacitor
• Rotation: Reversible
• Shaft Diameter: 0.500 in
• Shaft Extension: 6.0 in
