GENTEQ MOTORS 8203 Multi-Functional 1/70 HP Fan Motor REPLACEMENT 8767-8203

Product Description

The GENTEQ MOTORS 8203 is a thermally protected, open ventilated shaded pole multi-functional fan motor. With a diameter of three point three inches, it is suitable for various applications such as evaporator fans, bathroom exhaust fans, range hood exhaust fans, as well as humidifiers and dehumidifiers. The motor features a shaft that measures one quarter inch in diameter and two and one quarter inches in length.

• Thermally protected for safety
• Versatile use across multiple appliances
• Compact size for easy installation

Product Highlights

This GENTEQ MOTORS fan motor is essential for HVAC applications needing reliable performance.

Product Information

Standard Information

• Type: Fan Motor
• Power: 1/70 HP

Technical Specifications

• Speed: 1500 RPM
• Voltage: 115 Volts
• Horsepower: 1/70 HP
• Current: 0.7 Amps
• Rotation: CWSE
• Frequency: 60Hz
• Dimensions of Shaft: 1/4 inch diameter by 2-1/4 inch length
