Genteq Motors 5R023 ECM 3-7/8 Diameter Morrill Unit Bearing Commercial Refrigeration Motor

Product Description

The Genteq Motors 5R023 is an ECM motor designed for commercial refrigeration. It features a three and seven-eighths inch diameter with a Morrill unit bearing. This motor operates on two hundred thirty volts and draws zero point four five amps, delivering thirty-eight watts of power. It has a totally enclosed design for durability and is suitable for hub mounting, specifically for applications that require a single-speed motor with counterclockwise rotation.

• ECM (Electronically Commutated) motor
• Designed for commercial refrigeration
• Hub mounting for easy installation

Product Highlights

This motor is efficient and reliable for various refrigeration applications.

Product Information

Standard Information

• Brand: Genteq
• Condition: New

Technical Specifications

• Catalog#: 5R023
• Amps: 0.45 A
• Enclosure Type: TE (Totally Enclosed)
• Motor Diameter: 3-7/8 inches
• Mounting: Hub
• Number of Speeds: 1
• Phase: 1
• Output Watts: 38 W
• Rotation: CCW Shaft End
• RPM: 1550
• Voltage: 230 V
• Frame: UNIT BEARING
• Thermal Protection: Automatic
• Insulation Class: B
• UL Listed: Yes
• CSA Certified: Yes
• Shaft Type: 1/4-20 THREAD
• Overall Length: 4.59 inches
• Frame Length: 4.26 inches
• Shaft Diameter: 0.250 inches
