Genteq Motors 5H1023CW Direct Drive Motor 3/4 HP

Product Description

The Genteq 5H1023CW is a direct drive motor, suitable for HVAC systems. This motor has a diameter of five and a half inches and a power rating of three-fourths horsepower. It operates on 208-230 volts with single-phase power. The motor supports three speeds and delivers a speed of 1075 RPM with a current draw of 4.5 amps. One notable feature is its reversible design, which allows both clockwise and counter-clockwise rotation. Additionally, it has an Open Air Over enclosure and utilizes ball bearings for efficient operation. The shaft measures one-half inch by six and a half inches, making it ideal for use in direct drive blower applications.

• Capacitor: 10 MFD-370V
• Duty Cycle: Continuous Air Over
• Thermal Overload Protection: Yes

Product Highlights

This motor is designed for both durability and efficient operation in various HVAC applications.

Product Information

Standard Information

• Brand: Genteq
• Manufacturer: Regal Beloit Canada

Technical Specifications

• Hertz: 60 Hz
• Motor Mounting Style: Belly Band, Extended Studs, Mounting Holes in Shell
• Number of Poles: 6
• Voltage (V): 208-230/1
• Motor Type: 5.5 Diameter Motors, Direct Drive Blower Motors
• Motor Design: PSC
• Enclosure: Open Air Over
• NEMA Frame Size: 48
• Rotation: CW/CCW, REV
• RPM: 1075
• Number of Speeds: 3
• Amperage: 4.50 A
• Number of Shafts: 1
• Bearing Type: Ball
• Shaft Design: 90 Degree Double Flat
• Shaft Length: 6.5 inches
