GENTEQ MOTORS 4CL2433-4 Direct Drive Motor 3/4 HP

Product Description

The GENTEQ MOTORS 4CL2433-4 is a 3/4 HP Direct Drive Motor suitable for furnace and central air conditioning applications. This motor works on 208-230/1 voltage and has a diameter of 5.5 inches. It is designed for efficient operation with a speed of 1075 RPM and a current draw of 4.5 Amps. The motor supports reversible rotation and features an open air over enclosure, making it versatile and adaptable.

• Direct drive blower motor with 3/4 HP power.
• Operates at 208-230/1 voltage and 1075 RPM.
• Supports reversible rotation and features an open air over enclosure.

Product Highlights

Ideal for HVAC systems, this motor ensures reliability and efficiency in heating and cooling applications.

Product Information

Standard Information

• Brand: GENTEQ
• Horsepower Rating: 3/4

Technical Specifications

• Voltage (V): 208-230/1
• RPM: 1075
• Amperage: 4.50A
• Number of Speeds: 3
• Rotation: CW/CCW, REV
• Motor Type: 5.5 Diameter Motors, Direct Drive Blower Motors
• Motor Design: PSC
• Enclosure: Open Air Over
• Bearing Type: Ball
• Shaft Diameter (In.): 1/2
• Shaft Length (In.): 6-1/2
• Hertz: 60 Hz
• NEMA Frame Size: 48
• Weight (lbs): 19
