Genesis Cable 55021004 16/1-Pair Solid Unshielded Fire Alarm Cable 1000 feet Reel REPLACEMENT MPN

Product Description

The Genesis Cable 55021004 is a fire alarm cable designed to ensure uninterrupted fire protection. Built to exceed the demands of rigorous New York City fire safety code. This 16AWG cable features bare copper conductors, fluoropolymer insulation and jacket, and countdown length markings. It is UL listed and Made in the USA.

• Bare Copper conductors for excellent conductivity and low voltage drop
• Fluoropolymer insulation
• Fluoropolymer jacket
• Countdown Length Markings for easy tracking of usage and remaining cable

Product Highlights

This solid, unshielded fire alarm cable is FPLP rated and NYC certified. It is REACH/RoHS compliant and suitable for indoor use.

Product Information

Standard Information

• Brand: Genesis Cable
• Manufacturer Part Number: 55021004
• Country of Origin: US

Technical Specifications

• ADI Part Number: WG-55021004
• Brand Name: Genesis
• Manufacturer: Genesis Cable
• Manufacturer Part Number: 55021004
• Packaged Quantity: 1
• Product Model: 55021004
• Product Type: Fire Alarm Cables
• American Wire Gauge: 16AWG
• Armored: No
• Cable Rating: Plenum
• Conductor Count: 2
• Conductor Material: Bare Copper
• Jacket Material: PVDF
• Jacket Type: Plenum
• Number of Conductors: 2
• Number of Pairs: 1
• Shielding: No
• Solid or Stranded: Solid
• TAA Compliant: Yes
• Cable Length: 1000'
• Color: Red
• Insulation Material: PVDF
• Package Type: Reel/Spool
• Environmental Certification: RoHS
• Indoor/Outdoor: Indoor
• Voltage Rating: 300 V
• Temperature Rating: -20 To 150 Deg C
• Compliance: NYC Rated
• NFPA 262: UL1424
