Product Description
The Genesis Cable 52865008 Audacious Sound Cable is direct burial rated and suitable for outdoor locations. Features oxygen-free bare copper conductors for excellent sound transmission and low voltage drop. Includes a durable rip cord for efficient jacket stripping and removal, and Countdown Length Markings for easy tracking of usage. Rated for 300 Volts and -20 °C to 60 °C.
- Direct Burial Rated
- Sunlight Resistant Rated
- Oxygen-Free Bare Copper conductors for excellent sound transmission and low voltage drop.
- Durable rip cord for efficient jacket stripping and removal.
Product Highlights
This 14 AWG cable has 4 stranded, unshielded conductors and is REACH/RoHS compliant. Ideal for outdoor audio and speaker applications.
Product Information
Standard Information
-
Brand: Genesis Cable
-
Manufacturer Part Number: 52865008
-
Country of Origin: US
Technical Specifications
-
Size (AWG or kcmil): 14 AWG
-
No. of Conductors: 4
-
Stranding: Stranded
-
Shielding: Unshielded
-
Nominal Total Weight (lbs/1000'): 94
-
ADI Part Number: WG-52865008
-
Brand Name: Genesis
-
Manufacturer: Genesis Cable
-
Manufacturer Part Number: 52865008
-
Packaged Quantity: 1
-
Product Line: Audacious Sound Cable
-
Product Model: 52865008
-
Product Type: Audio & Speaker Cables
-
American Wire Gauge: 14AWG
-
Armored: No
-
Cable Rating: General Purpose
-
Conductor Count: 4
-
Conductor Material: Oxygen-Free Bare Copper
-
Core/Cladding Diameter: 14/4
-
Jacket Material: PVC
-
Jacket Type: Direct Burial, Outdoor
-
Number of Conductors: 4
-
TAA Compliant: Yes
-
Cable Length: 500'
-
Insulation Material: SR-PVC
-
Package Type: Reel/Spool
-
Environmental Certification: RoHS
-
Indoor/Outdoor: Outdoor
-
Material: Polyvinyl Chloride (PVC) - Jacket
-
Connector on Second End: Bare Wire
-
Connector on First End: Bare Wire
-
Features: Stranded
