Product Description
The Genesis Cable 45261004 is a plenum-rated, unshielded fire alarm cable suitable for installation in fabricated ducts, environmental air spaces, and risers. It features 4 stranded 16 AWG bare copper conductors, low-smoke PVC insulation, and a plenum PVC jacket. The cable is marked with Countdown length markings for easy tracking.
- Bare copper conductors for excellent conductivity.
- Low-smoke PVC insulation and plenum PVC jacket.
- Durable rip cord for efficient jacket stripping.
Product Highlights
This Genesis fire alarm cable ensures uninterrupted fire protection, exceeding rigorous fire safety codes and regulations. It is UL listed and made in the USA.
Product Information
Standard Information
-
Brand: Genesis Cable
-
Manufacturer Part Number: 45261004
-
Country of Origin: United States
Technical Specifications
-
Size (AWG or kcmil): 16 AWG
-
No. of Conductors: 4
-
Stranding: Stranded
-
Shielding: Unshielded
-
Product Name: 16/4 STR FPLP/CMP 1M RL Red
-
Product Model: 45261004
-
Packaged Quantity: 1
-
Product Type: Control Cable
-
Cable Type: Bare Wire
-
Cable Length: 1000'
-
Connector Type on First End: Bare Wire
-
Connector Type on Second End: Bare Wire
-
Jacket Type: Plenum, FPLP, CL3P, FT6, Riser, CMP
-
Device Supported: Fire Alarm
-
American Wire Gauge: 16 AWG
-
Number of Conductors: 4
-
Features: Stranded
-
Product Color: Red
-
Insulation Color: Black, Red, Green, White
-
Product Material: Bare Copper
-
Insulation Material: Polyvinyl Chloride (PVC)
-
Jacket Material: LS-PVC
-
Environmentally Friendly: Yes
-
Country of Origin: United States
-
Conductor: Bare Copper
-
Material Details: Bare Copper - Conductor
-
Manufacturer: Genesis Series Cable by Honeywell
-
Manuf Part#: 45261004
-
Environmental Certification: RoHS
-
Cable Rating: Plenum
-
Conductor Count: 4
-
Conductor Material: Bare Copper
-
Core/Cladding Diameter: 16/4
-
Solid or Stranded: Stranded
-
TAA Compliant: Yes
-
Package Type: Reel/Spool
-
Indoor/Outdoor: Indoor
-
Construction: 16/4 Stranded
-
Applications: Fire Alarm, Plenum, Unshielded
-
Color: Red
-
Reel Length: 1000 ft
-
voltage rating: 300 V
-
temperature rating: -20 To 75 Deg C
