Product Description
The Genesis Cable 45121004 Plenum Rated Unshielded Fire Alarm Cable is suitable for installation in fabricated ducts, other spaces used for environmental air, in risers, and within buildings in other than air-handling spaces and risers. It features bare copper conductors, low-smoke PVC insulation and plenum PVC jacket. Rated for 300 Volts and -20 °C to 75 °C.
- Bare Copper conductors for excellent conductivity and low voltage drop
- Low-Smoke PVC insulation
- Plenum PVC jacket
- Durable rip cord for efficient jacket stripping and removal
Product Highlights
This Genesis fire alarm cable ensures uninterrupted fire protection with its solid 16 AWG conductors and plenum rating, making it ideal for dependable fire alarm system wiring.
Product Information
Standard Information
-
Brand: Genesis Cable
-
Manufacturer Part Number: 45121004
-
Country of Origin: United States
Technical Specifications
-
Size (AWG or kcmil): 16 AWG
-
No. of Conductors: 4
-
Stranding: Solid
-
Shielding: Unshielded
-
Nominal Total Weight (lbs/1000'): 41
-
Brand Name: Genesis
-
Manufacturer: Genesis Cable
-
Manufacturer Part Number: 45121004
-
Packaged Quantity: 1
-
Product Model: 45121004
-
Product Name: 16/4 Sol FPLP 1M RL Red
-
Product Type: Fire Alarm Cables
-
American Wire Gauge: 16 AWG
-
Armored: No
-
Cable Rating: Plenum
-
Conductor Count: 4
-
Conductor Material: Bare Copper
-
Core/Cladding Diameter: 16/4
-
Jacket Material: LS-PVC
-
Jacket Type: Plenum
-
Solid or Stranded: Solid
-
TAA Compliant: Yes
-
Cable Length: 1000'
-
Color: Red
-
Insulation Material: LS-PVC
-
Package Type: Reel/Spool
-
Country of Origin: US
-
Environmental Certification: RoHS
-
Indoor/Outdoor: Indoor
-
Print Legend: GENESIS P/N 4512 4C 16AWG E175105 (UL) FPLP OR CL3P FT6 75C
-
UPC: 619172016575
-
Riser: FPLP
-
CL3P: FT6
-
Device Supported: Fire Alarm
-
Insulation Color: Black, Red, Green, Yellow
-
Product Material: Bare Copper
-
Environmentally Friendly: Yes
-
Packing: Spool
-
Conductor: Copper
-
Material Details: Bare Copper - Conductor
-
Type: Solid
-
Shielded: No
-
Length: 1000Ft.
