Genesis Cable 45111004 Fire Alarm Unshielded Cable, Plenum

Product Description

The Genesis Cable 45111004 is a plenum-rated, unshielded fire alarm cable suitable for installation in fabricated ducts, environmental air spaces, risers, and within buildings. It features bare copper conductors for excellent conductivity and low voltage drop. This cable is rated for 300 Volts and for temperatures between -20 °C to 75 °C.

• Bare Copper conductors for excellent conductivity and low voltage drop.
• Low-Smoke PVC insulation.
• Plenum PVC jacket.

Product Highlights

Plenum-rated unshielded fire alarm cable with bare copper conductors, low-smoke PVC insulation and a plenum PVC jacket.

Product Information

Standard Information

• Brand: Genesis Cable
• Manufacturer Part Number: 45111004

Technical Specifications

• Size (AWG or kcmil): 16 AWG
• No. of Conductors: 2
• Stranding: Solid
• Shielding: Unshielded
• Nominal Total Weight (lbs/1000'): 23
• Material: Copper
• Voltage: 300 Volts
• Item model number: 45111004
