Product Description
The GENESIS 32140312 is an 18/2 Str OAS Plenum Cable with a length of 250ft. This shielded multiconductor cable features bare copper conductors and low-smoke PVC insulation. It is suitable for installation in ducts, environmental air spaces, risers, and within buildings. The cable is rated for 300 Volts and for temperatures from -20 °C to 75 °C.
- Features bare copper conductors for excellent conductivity
- Has low-smoke PVC insulation and plenum PVC jacket
- Rated for 300 Volts and temperatures from -20 °C to 75 °C
Product Highlights
This GENESIS plenum rated shielded multiconductor cable is ideal for low voltage circuits, offering excellent conductivity and durability.
Product Information
Standard Information
-
Brand: GENESIS
-
Manufacturer Part Number: 32140312
-
Country of Origin: Country of origin is subject to change.
Technical Specifications
-
Length: 250 ft
-
Shielded: Yes
-
Packaging: Reel
-
Conductors: 2
-
Gauge (AWG): 18
-
Jacket Color: Natural
-
Jacket Rating: Plenum
-
Conductor Type: Stranded
-
Wire Type: Low Voltage
-
Voltage: 300v
-
Features: Plenum-Rated
-
Outside Diameter: 0.154 in
-
Application: Multi-Purpose
-
Package Type: Reels
-
Approvals: C(UL), FT6, CMP, OAS, CL2P
-
Size (AWG or kcmil): 18 AWG
-
Nominal Total Weight (lbs/1000'): 19
-
Insulation Material: LS-PVC
-
Jacket Material: LS-PVC
-
Resistance: 6.66 Ohm/1000 ft at 20 deg C
-
Series: 3214
-
Strands: 19
-
Temperature Rating: -20 to 75 deg C
-
Type: Multipurpose
-
Voltage Rating: 300 V
-
Number of Pairs: 1
-
Conductor Material: Bare Copper
-
American Wire Gauge: 18AWG
-
Cable Rating: Plenum
-
Solid or Stranded: Stranded
-
TAA Compliant: Yes
-
Environmental Certification: RoHS
-
Number of Conductors: 2
