General Hvac Solutions AUU12RLF Airstage Single-Room Mini-Split Systems Floor Mounted RLFF Series 12,000 BTU/h

Product Description

The GENERAL HVAC SOLUTIONS AUU12RLF Airstage Single-Room Mini-Split Systems Floor Mounted RLFF Series features an indoor unit (AGU12RLF) and an outdoor unit (AOU12RLFF). This system offers up to 26 SEER and provides both cooling and heating capabilities. It is designed for energy efficiency and flexible installation. The unit operates within a cooling range of 14~115�F and a heating range of -5~75�F.

• Compact Size
• Energy Efficient
• 2-Fan and Wide Airflow
• High Performance Heating

Product Highlights

This mini-split system is energy efficient and offers both cooling and heating. It features a compact size and is designed for flexible and easy installation.

Product Information

Standard Information

• Brand: GENERAL HVAC SOLUTIONS
• Manufacturer Part Number: AUU12RLF

Technical Specifications

• Power Source: 208-230/60/1
• Capacity Cooling BTU/h: 12,000(3,100~14,300)
• Capacity Heating BTU/h: 16,000(3,100~22,100)
• HSPF BTU/hW: 11.6
• SEER BTU/hW: 22.7
• EER Cooling/Heating W/W: 13.1/11.1
• Operation Range Cooling �F(�C): 14~115 (-10~46)
• Operation Range Heating �F(�C): -5~75 (-21~24)
• Moisture Removal Pt./h(l/h): 3.8 (1.8)
• MAX.CRT.BKR A: 15
• Air Circ. C.F.M. Hi (m�_/h): 335 (570)
• Air Circ. C.F.M. Medium: 271 (460)
• Air Circ. C.F.M. Low: 212 (360)
• Air Circ. C.F.M. Quiet: 159 (270)
• Noise Level Hi dB(A) 15RLS3: 40/40
• Noise Level Medium: 35/35
• Noise Level Low: 29/29
• Noise Level Quiet: 23/23
• Outdoor Fan Speed RPM: 1,050/870
• Outdoor Noise Level dB(A) Clg/Htg: 52/52
• Current Cooling A: 4.2
• Current Heating A: 6.7
• Power Use Cooling kw: .97
• Power Use Heating kw: 1.44
• Fan Speeds Stage: 4+Auto
• Air Direction Horizontal: Manual
• Air Direction Vertical: Automatic
• Air Filter Washable: Yes
• Apple Catechin Filter: Yes
• Ion Deoderizing Filter: Yes
• Connection Method: Flare
• Combined Min.Lgth Ft (m): 10 (3)
• Max.Lgth: 66 (20)
• Max. Vertical Diff. Ft (m): 49 (15)
• Conn. Pipe Diameter Indoor Inch Suc.: 3/8
• Conn. Pipe Diameter Outdoor Dis.: 1/4
• Refrigerant (Global Warming Potential): R410A
