General Filters 1602 Spin-on Fuel Oil Filter with Bracket

Product Description

The GENERAL FILTERS 1602 is a spin-on fuel oil filter assembly designed for residential and light commercial oil-fired heating systems. It combines a machined aluminum head with an epoxy-coated disposable spin-on filter element and a galvanized steel mounting bracket in a single kit. The unit delivers 10-micron particulate removal across 500 square inches of filtering area, with a rated flow rate of 45 gallons per hour and a working pressure of 15 psi. A 1/8-inch vacuum and bleed port is built into the head for easy servicing. Fuel oil technicians and HVAC-O technicians install this filter as part of routine oil burner service or system upgrades.

The 1602 is suited for residential fuel oil delivery systems serving oil burners rated up to 10 gallons per hour maximum firing rate. The assembly mounts vertically on the included galvanized bracket, which supports two installation positions. The epoxy-coated spin-on element accepts a B100 BIOGasket for biodiesel-compatible installations. The 3/8-inch NPT inlet and outlet connect directly to standard fuel oil supply lines commonly found in residential heating applications.

Key Features

• Machined aluminum filter head with 1/8-inch vacuum and bleed port for easy air removal and service
• Epoxy-coated disposable spin-on filter element rated for 10-micron particulate removal
• 500 square inches of filtering area supports flow rates up to 45 gallons per hour
• B100 BIOGasket included for biodiesel fuel compatibility
• Galvanized steel mounting bracket with two field-selectable mounting positions
• 3/8-inch NPT inlet and outlet for direct connection to standard fuel supply lines

Compatibility

Designed as an OEM-style replacement or upgrade spin-on fuel oil filter for residential oil-fired heating systems with a maximum burner firing rate of 10 gallons per hour and fuel supply lines using 3/8-inch NPT connections.

Installation Notes

Installation should be performed by a licensed oil burner technician or qualified HVAC-O service professional. Shut off the fuel supply valve and depressurize the line before removing the existing filter or head assembly. Use the bleed port to purge air from the filter after installation before firing the burner. Verify all NPT fittings are leak-free using an approved thread sealant rated for fuel oil service.

Technical Specifications

• Maximum Firing Rate: 10 gallons per hour
• Micron Removal: 10 microns
• Filtering Area: 500 square inches
• Working Pressure: 15 psi
• Flow Rate: 45 gallons per hour
• Inlet/Outlet: 3/8-inch NPT
• Bracket Up Position Height: 9.25 inches
• Bracket Down Position Height: 7.5 inches
• Bracket Down Position Width: 3.75 inches
• Head Material: Machined Aluminum
• Bracket Material: Galvanized Steel
• Filter Element Coating: Epoxy-Coated

Standard Information

• Brand: GENERAL FILTERS
• Manufacturer Part Number: 1602
