General Electric THQC2130 Molded Case Circuit Breaker 30A 2P

Product Description

The General Electric THQC2130 is a molded case circuit breaker designed for residential and commercial settings. It provides protection at a rated current of thirty amps and features two poles. Users can trust its robust safety mechanisms and efficient design.

• Circuit breaker is designed to handle fault currents effectively.
• Suitable for use in diverse electrical environments.
• Easy mounting options ensure straightforward installation.

Product Highlights

This breaker is essential for maintaining electrical safety in your systems. With a UL approval and an interrupting capacity of ten kiloamperes, it meets compliance standards.

Product Information

Standard Information

• Manufacturer: General Electric
• UPC: 783164116618

Technical Specifications

• Type: Molded Case, Fixed Thermal Magnetic, Internal Common Trip
• Number of Poles: 2
• Voltage Rating: 120/240 VAC
• Amperage Rating: 30 A
• Interrupting Rating: 10 Kiloampere
• Mounting Type: 35 MM DIN Rail
• Dimensions: 2 inches x 2.38 inches x 3.28 inches
• Wire Size: 14 to 8 AWG (Copper) / 12 to 8 AWG (Aluminum)
• Used On: Panelboard
