General Electric THQB1125 Type THQB Molded Case Miniature Supplementary Protector, 120/240 VAC, 25 A, 10 kA Interrupt

Product Description

The General Electric THQB1125 is a Type THQB Molded Case Miniature Circuit Breaker. It is rated for 120/240 VAC and delivers 25 A of power with a ten kA interrupt capacity. This product features one pole and is designed for use in residential and commercial environments.

• Bolt-on design for load centers and lighting panels
• Quick-make, quick-break mechanism for reliability
• Fixed instantaneous trip function

Product Highlights

This circuit breaker ensures safety with its quick trip indication and is suitable for various electrical distribution and control applications.

Product Information

Standard Information

• Brand: General Electric
• MPN: THQB1125

Technical Specifications

• Amperage Rating: 25 A
• Voltage Rating: 120/240 VAC
• Interrupt Rating: 10 kA
• Trip Type: LI/Thermal Magnetic
• Mounting Type: Bolt-On
• Number of Poles: 1
• Dimensions: 3.28 inches H x 1 inch W x 2.38 inches D
• Temperature Rating: 40 degrees C
• Wire Size: 14 to 8 AWG, 12 to 8 AWG
• Country of Origin: UU
• Mfg Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL File No. E11592, CSA Certified
