General Electric THHQB32100 Bolt-On Circuit Breaker 100A 3P 22K

Product Description

The General Electric THHQB32100 is a bolt-on circuit breaker with a current rating of one hundred amps and three poles. Designed for use in both residential and commercial applications, this circuit breaker has an interrupting rating of 22 kiloamperes. It features a molded case, fixed thermal magnetic design with an internal common trip.

• Approval: UL certified
• Mounting Type: Bolt-On, size one inch
• Compatible with AQ Series Panelboard

Product Highlights

This product ensures circuit protection with reliable thermal magnetic trips. It is useful for load centers and lighting panels in various settings.

Product Information

Standard Information

• Manufacturer: General Electric
• UPC: 783164118674

Technical Specifications

• Current Rating: 100 A
• Number of Poles: 3
• Interrupting Rating: 22 Kiloampere
• Wire Size: 6 to 1/0 AWG (Copper), 4 to 1/0 AWG (Aluminum)
• Dimensions: 3 inches x 2.38 inches x 3.28 inches
• Terminal Type: Copper/Aluminum Load Lug, Bolt-On
