General Electric THHQB1120 Bolt-On Circuit Breaker 20A 1P 22K

Product Description

General Electric THHQB1120 is a bolt-on circuit breaker with a capacity of twenty amperes. It features a unique thermal magnetic trip and is designed for use in residential and commercial applications. The breaker's compact size allows for easy installation in various load centers.

• Rated for twenty amperes and designed with one pole.
• Interrupting rating of twenty-two kiloamperes.
• Compatible with AQ series panelboards.

Product Highlights

This circuit breaker is suitable for a range of electrical distribution and control applications. It ensures safety and reliability with its quick-make and quick-break operation.

Product Information

Standard Information

• Manufacturer: General Electric
• Product UPC: 783164118247

Technical Specifications

• Approval: UL
• Number of Poles: 1
• Interrupting Rating: 22 Kiloampere
• Mounting: 1 Inch Bolt-On
• Type: Molded Case, Fixed Thermal Magnetic
• Wire Size: 14 to 8 AWG (Copper), 12 to 8 AWG (Aluminum)
• Dimensions: 1 inch x 2.38 inches x 3.28 inches
• Terminal Type: Copper/Aluminum Load Lug, Bolt-On
• Used On: AQ Series Panelboard
