General Electric SRPF250A150 Ged Spectra F 150A

Product Description

The General Electric SRPF250A150 is a replacement rating plug designed for Spectra circuit breakers. It establishes or changes the long-time trip point of a circuit breaker.

• Breaker rating plug for SF250 frame type.
• Maximum breaker current rating of 150 Amp.
• Meets UL approval standards.

Product Highlights

This rating plug provides flexibility by allowing interchangeable rating for enhanced control of circuit breaker ampacity settings.

Product Information

Standard Information

• Manufacturer: General Electric
• UPC: 78316421321

Technical Specifications

• Breaker Frame Type: SF250
• Plug Current Rating: 150A
• Maximum Breaker Current Rating: 250A
• Dimensions: 4 inches L x 3 inches W x 1-3/4 inches H
• Standard & Approvals: CSA LR40350, IEC 947-2, UL E11592
• Weight: 1.01 lbs
• Special Features: Adjustable instantaneous trip range 440 to 1500 A
• Suitable For Use With: SF Series Molded Case Circuit Breakers
