General Electric nchc48ct4 Cased Evaporator Coil 4 Ton

Product Description

The GENERAL ELECTRIC nchc48ct4 is a 4-ton cased evaporator coil configured for horizontal airflow applications. Built with aluminum alloy tube and fin construction, this coil is designed to handle heat transfer duties in split-system air conditioning and heat pump setups. Pre-formed flanges simplify cabinet integration and help maintain an airtight fit during installation. At 56.05 pounds net weight, the unit is sized for residential and light commercial systems where a horizontally oriented air handler or cased coil position is required. Licensed HVAC technicians are the intended installers for this component.

This coil is suited for horizontal cased installations in attic, closet, or utility-room air handler configurations. The cased design allows it to drop into a compatible air handler cabinet or coil cabinet without the need for additional sheet metal fabrication. The C-cabinet form factor is intended for 4-ton system capacities. Where space constraints require horizontal coil orientation, this unit provides the correct geometry and airflow path to match the system design.

Key Features

• Aluminum alloy tube and fin construction for corrosion resistance and efficient heat transfer
• Horizontal airflow configuration for attic or utility-room installations
• Cased design with pre-formed flanges for straightforward cabinet integration
• 4-ton capacity matched to standard residential and light commercial system sizing
• Limited 5-year parts warranty standard; extendable to limited 10-year with registration
• Gray exterior finish for a clean, finished appearance in installed systems

Compatibility

Designed as an OEM-style replacement or new-installation cased evaporator coil for horizontal-airflow split systems rated at 4 tons.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local codes and manufacturer guidelines. Disconnect all power to the air handler and recover any system refrigerant before removing or installing the coil. Verify that the cabinet or coil box dimensions match the C-cabinet form factor before securing the unit. After installation, the refrigerant circuit must be leak-tested and the system properly evacuated and charged before startup.

Technical Specifications

• Product Type: Evaporator Coil
• Tonnage: 4 tons
• Configuration: Cased
• Airflow: Horizontal
• Coil Material: Aluminum alloy tube and fin
• Color: Gray
• Net Weight: 56.05 pounds
• Approximate Shipping Weight: 59 pounds
• Parts Warranty: Limited 5-year; limited 10-year with registration
• Labor Warranty: No warranty

Standard Information

• Brand: GENERAL ELECTRIC
• Manufacturer Part Number: nchc48ct4
