General Electric G6503VUI ECM Replacement Blower Motor

Product Description

The General Electric G6503VUI is an ECM replacement blower motor suitable for various applications. It operates on a voltage range of 115/208-230V and consumes current of 4.5/2.9-2.7 Amps. This motor is equipped with auto-rotation sensing technology and supports tap inputs at 24Vac. It is designed for constant torque performance and complies with NEMA 48 standards. The motor features an open air over (OAO) design and can achieve efficiency ratings up to 82%. It is also compatible with belly-band mounting.

• Operates at 115/208-230V and 4.5/2.9-2.7 Amps
• Features auto-rotation sensing and supports 24Vac tap inputs
• Compatible with belly-band mounting

Product Highlights

The General Electric G6503VUI is perfect for use in HVAC applications where reliable airflow is essential.

Product Information

Standard Information

• Brand: General Electric
• MPN: G6503VUI

Technical Specifications

• Horsepower: 1/3
• Input Voltage: 115/208-230
• Input Current: 4.5/2.9-2.7
• RPM: 1075/VAR
• Shaft Dimensions: 1/2 x 5
• Body Length: 5.48
• Frequency: 50/60 Hz
