General Electric AZVS15DCXWA Zoneline Heat Pump Unit with Variable Speed Inverter Technology and Corrosion Protection 15,000 BTU, 230/208 Volt

Product Description

The GENERAL ELECTRIC AZVS15DCXWA Zoneline Perfect Control units use environmentally friendly refrigerants, helping commercial buildings meet LEED standards. Variable speed operation provides shorter recovery time, improved efficiency, sound quality and dehumidification. Advanced defrost capability allows for extended heat pump down to 0°F. An easy-to-read interface simplifies navigation.

• Designed & Assembled in America
• Eco-Friendly Build
• Inverter Technology

Product Highlights

This GE Zoneline heat pump offers unrivaled reliability backed by a dedicated service network. It is made of the highest quality material and tested in extreme environments.

Product Information

Standard Information

• Brand: GENERAL ELECTRIC
• Manufacturer Part Number: AZVS15DCXWA
• Country of Origin: America

Technical Specifications

• Accessories: Accessories Required for Installation RAB42 - Wall Case Outdoor Grille
• CFM Indoor Fan High: 525
• CFM Indoor Fan Low: 250
• Cool BTUH (208V): 14200
• Cool BTUH (230V): 14300
• Cooling BTUH (MAX): 14300
• Cooling EER (BTUH / Watt): 11.0 / 10.9
• Dehumidification (pts./hr.): 2
• Vent CFM (high fan at zero ESP): 45
• Central Desk Control Compatibility: Yes
• Chassis Type: Slide-In
• Control Type: Standard Microcomputer
• Tactile touch pad with LED Display: Yes
• Corrosion Treated: Yes
• Discharge Grille: 2-position
• Electronic Micro Computer Control: Yes
• Fan Cycle Switch: Yes
• Fan Motor: 2
• EC Controlled: Yes
• Fan Speed Control: Yes
• Fan Speed Selections: Hi/Low Cooling Hi/Low Heating Hi/Low Fan Only
• Filter Type: Rigid Frame
• Freeze Sentinel: Yes
• Heat - Cool: Yes
• Heat Pump: Yes
• Heat Sentinel: Yes
• Heating - Reverse Cycle - COP: 3.4/3.4
• Heating System: E Heat/High Demand/Hybrid/Boost/HP Only
• HSPF2 Rating: 7
• Louver Style: Reversible
• Manual Vent Control: Hidden
• Power Factor: 95
• Product Type: Packaged Terminal Air Conditioners (PTAC)
• Refrigerant Charge (oz.): 29
• Refrigerant Type: R454B
• Rotary Compressor: Yes
• SEER2: 16
• Sensible Heat Ratio: 0.75
• Temperature Limiting: Electronic 24-Step
• Temperature Range: 60 - 85 F
• Vent Control: 3-position
• Venting Features: Concealed Manual Vent Control Vent Air Filter Outdoor Vent Control - 3 Positions
• WiFi Connect: Built-In
• Zoneline Features: "Smart Fan" Fan Cycle Control Heat Sentinel Freeze Sentinel Automatic Indoor Frost Control Universal Heaters Auto Power Recovery Remote Thermostat Compatibility Central Desk Control Compatibility Random Twist/Length Segment Tangential Blower
• Cooling - Amperes: 5.8/6.4
• Cooling - Watts: 1295/1300
• Heating BTUH: 4,000 - 14,000
• Heating - Electric - Heater Amps: 5.2/5.8
• Heating - Electric - Heater Watts: 1165
• Voltage (MAX): 230 V
• Voltage (MIN): 208 V
• Net Weight: 112 lb
• Overall Depth: 20.8125 in
• Overall Height: 16 in
• Overall Width: 42 in
• SEER: 16
• Energy Efficiency Ratio: 10.7 EER
• Heating Seasonal Performance Factor: 7 HSPF
• Coefficient of Performance (at 47 F): 3.4 COP
• Tonnage: 1.2 Ton(s)
• PTAC Cooling: 15000 BTUs
• PTAC Heat Pump: 15000 BTUs
• High Output Cool: 15000 BTU
• Heat Pump Heating BTUs: 4000 - 14000 BTUs
• Electric Heater Capacity (BTUs): 11500 / 9400 BTU
• Compressor Type: Rotary
• Voltage: 208 - 230 Volts
• Frequency: 60 Hz
• Voltage Phase: 1
• Maximum Fuse/Breaker: 20 Amps
• Depth: 21.8125 Inches
• Cut-Out Dimensions, W x H: 42 x 16 inches
• AHRI#: 215445944
• California Approved PTAC: Yes
• Moisture Removal Capacity Pints Per Day: 48
• Heater Included: Yes
