General Electric AZHS07ECXXA Zoneline Heat Pump 7,000 BTU, 265 Volt

Product Description

The GENERAL ELECTRIC AZHS07ECXXA Zoneline Heat Pump is a fixed speed unit with corrosion protection, operating at 265 Volts and 7,000 BTU. Designed and assembled in America, this unit features electronic touch controls with LED display and a quiet operation due to its baked-on mastic sound barrier. It uses R454B refrigerant and includes a fresh air vent.

• Features a corrosion protection package with SMC basepan and bulkhead.
• Equipped with electronic temperature limiting and a heat pump that functions down to 25°F.
• Offers a boost heat option and date of manufacture is 2025 or later.

Product Highlights

This GE Zoneline heat pump provides efficient heating and cooling with user-friendly controls and robust construction.

Product Information

Standard Information

• Brand: GENERAL ELECTRIC
• Manufacturer Part Number: AZHS07ECXXA
• Country of Origin: US

Technical Specifications

• ACCESSORIES: Accessories Required for Installation RAB42 - Wall Case Outdoor Grille
• Color Appearance: Grey White
• CFM Indoor Fan High: 335
• CFM Indoor Fan Low: 240
• Cooling BTUH (MAX): 7,100 Btu
• Cooling BTUH (MIN): 6100
• Cooling EER (BTUH / Watt): 12.7
• Dehumidification (pts./hr.): .9 (High Speed)
• Vent CFM (high fan at zero ESP): 36.8
• Central Desk Control Compatibility: Yes
• Chassis Type: Slide-In
• Control Type: Standard Microcomputer
• Tactile touch pad with LED Display: Yes
• Corrosion Treated: Yes
• Discharge Grille: 2-position
• Electronic Micro Computer Control: Yes
• Fan Cycle Switch: Yes
• Fan Motor: 2
• Fan Speed Control: Yes
• Fan Speed Selections: Hi/Low Cooling, Hi/Low Fan Only, Hi/Low Heating
• Filter Type: Rigid Frame Slide-Out
• Freeze Sentinel: Yes
• Heat - Cool: Yes
• Heat Pump: Yes
• Heat Sentinel: Yes
• Heating - Reverse Cycle - COP: 4
• Heating System: Heat Pump With Backup Resistance Heat
• Louver Style: Reversible
• Manual Vent Control: Hidden
• Power Factor: 95
• Product Type: Packaged Terminal Air Conditioners (PTAC)
• Refrigerant Charge (oz.): 26.5
• Refrigerant Type: R454B
• Rotary Compressor: Yes
• Sensible Heat Ratio: 0.75
• Temperature Limiting: Electronic 24-Step
• Temperature Range: 60 - 85 F
• Vent Control: 3-position
• Venting Features: Concealed Manual Vent Control Vent Air Filter Outdoor Vent Control - 3 Positions
• Zoneline Features: "Smart Fan" Fan Cycle Control Heat Sentinel Freeze Sentinel Automatic Indoor Frost Control Universal Heaters Auto Power Recovery Remote Thermostat Compatibility Central Desk Control Compatibility Random Twist/Length Segment Tangential Blower
• Cooling - Amperes: 2.3
• Cooling - Amperes; F.L. - Cooling: 2.2
• Cooling - Amperes; L.R.: 11.7
• Cooling - Watts: 555
• Heating BTUH: 6100
• Heating - Electric - Heater Amps: 1.9
• Heating - Reverse Cycle - Watts: 460
• Voltage (MAX): 265 V
• Overall Depth: 20.8125 in
• Overall Height: 16 in
• Overall Width: 42 in
• Manufacturer: GE
• Manufacturer Sku: AZHS07ECXXA
• Condition: New
• Cooling BTU: 7,000 BTU
• Machine Volts: 265/277 commercial
• Machine Amps: Universal
• Cord Included: No
• Plug Type: Universal
• Controls: Electronic
• Heat: Heat Pump
• Heater Size (KW): Universal
• Fits Standard 42" x 16" Sleeve: Yes
• Energy Star Certified: No
• Wi-Fi Compatible: No
• Remote Control: No
• Automatic Restart: Yes
• Seacoast Protection: Yes
• Freeze Protection: Yes
• Number of Fan Motors: 2
• Fan Speeds: 2
• ADA Compliant: No
• Energy Efficiency Rating (EER): 12.7
• COP Rating: 3.9
• Sleeve Included: No
• Exterior Grille Included: No
• Maximum Cooling Watts: 545
• Maximum Cooling Amps: 2.2
• Actual Cooling BTUs @ 265V: 7100
• CFM (Cool/Wet Coil) - High: 335
• CFM (Cool/Wet Coil) - Low: 240
• 4Less California Compliance: Yes
• Maximum Amperage: 1.6 Amp
• Maximum Voltage: 265V
• UL Listed: Yes
• Power Cord Included: No
