General Electric 9T58K0047 Transformer 240/480-120V 250VA

Product Description

The General Electric 9T58K0047 Transformer provides reliable voltage conversion for industrial and commercial electrical systems. Designed for efficiency, this transformer minimizes energy losses and ensures durability.

• Efficient voltage conversion
• Durable construction
• Low energy loss

Product Highlights

The 9T58K0047 Transformer is ideal for settings requiring dependable voltage conversion. It supports primary voltages of 240V to 480V and secondary voltages of 110V to 120V. This single-phase transformer is equipped with a screw terminal, suitable for various applications.

Product Information

Standard Information

• Brand: General Electric
• MPN: 9T58K0047

Technical Specifications

• Dimensions: 3.81 inches W x 5.12 inches D x 3.28 inches H
• Frequency Rating: 60 Hz
• Approvals: UL 506, CUL, CSA
• Standards: ANSI C89.2, NEMA ST-20
• Mounting Slot Size: 0.75 inches L x 0.219 inches W
• Power Rating: 0.25 KVA
• Terminal Type: Screw
• Primary Voltage: 220-440V, 230-460V, 240-480V
• Secondary Voltage: 110-120V
• Insulation Class: 180
• Power Rating in VA: 0.25
• Temperature Rise: 80 degrees C
• Number of Phases: 1
• Coil Material: Copper
• Ambient Temperature: 40 degrees C
• Frame Size: 8200
• Weight: 7 lbs
