General Electric 9T21S1150 GE 9T21S1150 480V 15KVA TFMR

Product Description

The General Electric 9T21S1150 is a dry type distribution transformer with a power rating of 15 kVA. It operates at a primary voltage of four hundred eighty volts AC at sixty hertz and has a secondary voltage of one hundred twenty/ two hundred forty volts. This transformer is designed for single phase applications.

• Power Rating: 15 kVA
• Primary Voltage: 480 VAC
• Secondary Voltage: 120/240 V

Product Highlights

The transformer features keyhole mounting flanges for easy installation and can be used both indoors and outdoors. The enclosure is rated NEMA 3R, providing protection against outdoor conditions.

Product Information

Standard Information

• Brand: General Electric
• MPN: 9T21S1150
• UPC: 78317301210

Technical Specifications

• Power Rating: 15 kVA
• Primary Voltage: 480 VAC at 60 Hz
• Secondary Voltage: 120/240 V
• Current Rating: 60 Ampere (Primary Main), 70 Ampere (Secondary Main)
• Number of Phases: 1
• Enclosure: NEMA 3R
• Size: 12.62 Inch W x 12.62 Inch D x 35 Inch H
• Weight: 280 lb
