General Electric 74456 Fluorescent Electronic Ballast 120-277V 2/3LP T8

Product Description

General Electric 74456 is a fluorescent electronic ballast designed for efficient lighting. This ballast supports a voltage range from one hundred twenty to two hundred seventy-seven volts. It is suitable for various fluorescent applications and can operate up to three lamps. The lightweight housing makes installation straightforward.

• High performance for all general fluorescent applications
• Multi-voltage capability from 120 to 277 volts
• Lightweight and low-profile design

Product Highlights

Designed for instant start, the General Electric 74456 ballast ensures a smooth operation with minimal flicker, enhancing the lifespan of your lamps.

Product Information

Standard Information

• Manufacturer: General Electric
• Product UPC: 043168744560

Technical Specifications

• Approval: UL, CUL
• Ballast Factor: 0.8 to 0.96
• Circuit Type: High Output
• Frequency Rating: 50/60 Hz
• Input Current: 0 to 0.73 Ampere
• Input Power: 34 to 75 W
• Input Voltage: 120 to 277 V
• Lamp Style: Linear
• Lamp Type: F17T8, F25T8, F28T8, F32T8, F40T8
• Lamp Wattage: 17/25/28/32/40 W
• Maximum THD: 18 Percent
• Minimum Starting Temperature: 0 Deg F
• Number Of Lamps: 2/3
• Power Factor: 0.96 to 0.99
• Size: 9.5 IN x 1.3 IN x 1.18 IN
• Starting Type: Instant
• Wiring: Parallel
