GE XT5HU340AFFN000XXX Type XT Molded Case Circuit Breaker 400A 3-Pole 600 VAC

Product Description

The GE XT5HU340AFFN000XXX is a molded case circuit breaker suitable for heavy-duty applications. This breaker has a frame rating of four hundred amps and operates at six hundred volts AC. It features a three-pole design with an interrupt rating of up to two hundred kiloamps at four hundred eighty volts and one hundred kiloamps at six hundred volts.

• Heavy-duty low voltage breaker for robust applications
• Three-pole configuration for reliable circuit protection
• Advanced electronic trip unit with field upgrade capability

Product Highlights

The SACE Tmax XT5 series provides high performance and flexible protection tailored for industrial settings.

Product Information

Standard Information

• Brand: GE
• Manufacturer: ABB - Low Voltage Drives

Technical Specifications

• Voltage Rating: 600 VAC
• Amperage Rating: 400 Amp
• Frame Size: XT5 400A
• Number of Poles: 3
• Interrupt Rating: 200 kA @ 480 VAC, 100 kA @ 600 VAC
• Frequency Rating: 50 - 60 Hz
• Trip Type: Ekip DIP LSI
• Dimensions: 5.51 Width x 4.05 Depth x 8.07 Height (inches)
