GE UHTRS101BGE 1-Position Meter Socket With Horn Bypass, 600 VAC, 125 A, 1 Phase, NEMA 3R Enclosure

Product Description

The General Electric UHTRS101BGE is a 1-position meter socket designed for residential and electrical distribution applications. It operates at 600 VAC and has an amperage rating of 125 A. This meter socket features a NEMA 3R enclosure, making it suitable for outdoor use. It is composed of G90 galvanized steel, ensuring durability against corrosion.

• Compatible with 14 to 2 AWG copper and aluminum connectors
• Supports heavy-duty connections with strong lug screws
• Includes an integral duplex ground extruded in the neutral lug

Product Highlights

This meter socket allows utilities to install a meter for monitoring and connecting power effectively.

Product Information

Standard Information

• Brand: GE
• Manufacturer: General Electric

Technical Specifications

• Type: 1-Position
• Amperage Rating: 125 A
• Voltage Rating: 600 VAC
• Dimensions: 10.88 inches H x 8 inches W x 3.5 inches D
• Wire Size: 8 to 2/0 AWG Cu/Al
• Enclosure Type: NEMA 3R
• Feed Type: Overhead
• Mounting Type: Surface
• Hub Type: Small Opening
• Cover Type: Ringless
• Number of Jaws: 4
