GE TM2010CCU Main Breaker Load Center 100 Amp 20 Circuit 120/240 VAC

Product Description

The GE TM2010CCU Main Breaker Load Center is designed for optimal performance for residential and commercial electrical distribution. This load center supports up to twenty circuits and is rated at 100 amps with a voltage of 120/240 VAC. Built for efficiency, it meets the requirements of the National Electrical Code when installed correctly.

• Rated for 100 amps, 120/240 VAC
• Features twenty circuits with THQL breakers
• Compact NEMA 1 enclosure for enhanced safety

Product Highlights

This load center is ideal for use in residential applications and complies with multiple safety standards.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part No: TM2010CCU

Technical Specifications

• Type: 1-Phase Standard
• Voltage Rating: 120/240 VAC
• Amperage Rating: 100 A
• Number of Poles: 1
• Interrupt Rating: 22 kA
• Number of Spaces: 20
• Wire Size: 4 to 1/0 AWG
• Mounting Type: Flush
• Enclosure Type: NEMA 1 and NEMA 6
• Dimensions: 23 inches H x 14 inches W x 3-3/4 inches D
