GE THQL32100 THQL Molded Case Circuit Breaker, 120/240 VAC, 100 Amp, 10 kAIC, 3 Poles

Product Description

The GE THQL32100 is a molded case circuit breaker rated for one hundred amps and designed for use at voltages of one hundred twenty to two hundred forty VAC. It features a ten kiloamp interrupt rating and includes three poles. This circuit breaker is suitable for residential and commercial applications.

• Ranges from 6 to 1/0 AWG wire size
• Plug-in mounting for easy installation
• LI/non-interchangeable thermal magnetic trip for reliable operation

Product Highlights

This circuit breaker integrates safety features such as a quick-make, quick-break mechanism and an internal common trip bar for enhanced protection.

Product Information

Standard Information

• Brand: GE
• Manufacturer: ABB Electrification

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 100 A
• Interrupt Rating: 10 kA
• Number of Poles: 3
• Trip Type: LI/Non-Interchangeable Thermal Magnetic
• Dimensions: 3-9/32 inches high x 3 inches wide x 2-3/8 inches deep
• Temperature Rating: 60/75 deg C
• Mounting Type: Plug-In
• Wire Size: 6 to 1/0 AWG (Copper), 4 to 1/0 AWG (Aluminum)
