GE THQL32080 THQL Compact Molded Case Circuit Breaker, 240 VAC, 80 Amp, 10 kAIC, 3 Poles

Product Description

The GE THQL32080 is a THQL compact molded case circuit breaker rated for 240 VAC and 80 amps. It features a ten kA interrupting capacity and includes three poles. This circuit breaker is designed for both commercial and residential use, providing reliable thermal magnetic protection.

• Plug-in installation for ease of use
• Trip indication via handle position
• Compact design with thermal magnetic operation

Product Highlights

This breaker is suitable for use in various electrical distribution applications. The compact design allows for easier installation in limited space settings, while the quick-make quick-break mechanism enhances safety during operation.

Product Information

Standard Information

• Manufacturer: General Electric
• Voltage Rating: 240 VAC

Technical Specifications

• Amperage Rating: 80 A
• Interrupt Rating: 10 kA
• Phase: 3
• Wire Size: 6 to 1/0 AWG (Copper), 4 to 1/0 AWG (Aluminum)
• Mounting Type: Plug-In
• Dimensions: 3-9/32 inches H x 3 inches W x 2-3/8 inches D
• Temperature Rating: 10 to 50 degrees C
