GE THQL32030 THQL Molded Case Circuit Breaker 120/240 VAC 30 Amp 10 kA 3 Poles

Product Description

GE THQL32030 is a THQL Molded Case Circuit Breaker rated for 120/240 VAC and 30 Amp. It is designed to handle a maximum interrupt current of 10 kA. This model is a three-pole breaker that is suited for various applications including residential and commercial use.

• Compact design at one inch per pole
• Thermal magnetic trip for reliable performance
• Plug-in mounting for ease of installation

Product Highlights

This circuit breaker features a LI/non-interchangeable thermal magnetic trip, ensuring effective protection against overloads and short circuits.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part No: THQL32030

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 30 A
• Number of Poles: 3
• Interrupt Rating: 10 kA
• Trip Type: LI/Non-Interchangeable Thermal Magnetic
• Frame: Q-Line
• Wire Size: 12 to 8 AWG
• Dimensions: 2-3/8 inches L x 1 inch W x 3-9/32 inches H
• Temperature Rating: 60/75 degrees C
• Mounting Type: Plug-In
• Application: Commercial, Residential, Thermal Magnetic, Electrical Distribution and Control Applications
• Manufacturer: General Electric
