GE THQL2150GFT THQL Self-Test GFCI Circuit Breaker, 120/240 VAC, 50 Amp, 10 kA Interrupt, 2 Poles, Non-Interchangeable/LIG Trip

Product Description

The GE THQL2150GFT is a self-test GFCI circuit breaker designed for use in residential and commercial electrical systems. This breaker operates at 120/240 VAC and provides a current rating of 50 Amps with a ten kA interrupt capacity. It features two poles and a non-interchangeable/LIG trip mechanism.

• Self-test functionality for enhanced safety.
• Designed to meet National Electrical Code requirements.
• Quick-make, quick-break mechanism for reliable protection.

Product Highlights

This circuit breaker is essential for preventing electrical shocks and overloads, particularly in areas such as kitchens and bathrooms where ground fault protection is necessary.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part No: THQL2150GFT

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 50 A
• Number of Poles: 2
• Interrupt Rating: 10 kA
• Trip Range: 5 mA
• Dimensions: 3-9/32 inches H x 2 inches W x 2-3/8 inches D
• Wire Size: 14 to 8 AWG Cu, 12 to 8 AWG Al
• Mounting Type: Plug-In
