GE THQL2140 THQL Molded Case Circuit Breaker, 120/240 VAC, 40 A, 10 kA Interrupt, 2 Poles, LI/Non-Interchangeable Thermal Magnetic Trip

Product Description

The GE THQL2140 is a THQL molded case circuit breaker designed for use in residential and commercial applications. This circuit breaker operates at 120/240 volts and has a 40 amp rating with a 10 kA interrupt capacity. It features a two-pole design and is ideal for various electrical distribution needs.

• LI/Non-Interchangeable Thermal Magnetic Trip
• Plug-in mounting for easy installation
• Compatible with 8 to 3 AWG copper and aluminum wire

Product Highlights

The THQL2140 is part of the Q-Line family of circuit breakers, known for reliability and ease of use in electrical systems. This model incorporates an internal common trip bar for enhanced protection.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part No: THQL2140

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 40 A
• Number of Poles: 2
• Interrupt Rating: 10 kA
• Trip Type: LI/Non-Interchangeable Thermal Magnetic
• Dimensions: 2-3/8 in L x 1 in W x 3-9/32 in H
• Mounting Type: Plug-In
• Wire Size: 8 to 3 AWG
• Temperature Rating: 60/75 deg C
