GE THQC2120WL Q-Line Molded Case Circuit Breaker 120/240 VAC 20 A 10 kA 2 Poles

Product Description

The General Electric Q-Line THQC2120WL is a type THQC molded case circuit breaker designed for use in various applications. This unit operates at 120/240 VAC with a current rating of twenty amperes and an interrupt rating of ten kiloamperes. It consists of two poles and features long time and instantaneous trip settings, making it suitable for residential and commercial use.

• Compact design for easy installation
• UL listed for safety and reliability
• Features quick make/quick break mechanisms

Product Highlights

The General Electric Q-Line breakers provide essential protection in electrical systems, supporting both standard and auxiliary contacts for expanded functionality.

Product Information

Standard Information

• Brand: GE
• Manufacturer: General Electric

Technical Specifications

• Type: Type THQC
• Amperage Rating: 20 A
• Trip Type: Long Time/Instantaneous
• Dimensions: 3-9/32 inches H x 2 inches W x 2-3/8 inches D
• Interrupt Rating: 10 kA
• Phase: 1
• Voltage Rating: 120/240 V
• Connection Type: Cable In/Cable Out (Line/Load Lug)
• Wire Size: 14 to 8 AWG/12 to 8 AWG
• Number Of Poles: 2
• Order Interval: 1
• Minimum Order Qty: 1
