GE THQB32100 THQB Miniature Circuit Breaker, 120/240 VAC, 100 Amp, 10 kAIC, 3 Poles

Product Description

GE Miniature Circuit Breaker, MPN: THQB32100 is designed for both residential and commercial applications. This thermal magnetic circuit breaker operates at 120/240 VAC and is rated for 100 amps. It features a 10 kA interrupt rating and uses a fixed trip function.

• Compact design with three poles
• Quick-make, quick-break mechanism for safety
• Compatible with various wire sizes and types

Product Highlights

This circuit breaker is suitable for use in AQ series panelboards, ensuring safety and reliability in electrical distribution systems.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part No: THQB32100

Technical Specifications

• Voltage Rating: 120/240 VAC
• Amperage Rating: 100 A
• Interrupt Rating: 10 kA
• Number of Poles: 3
• Frame Type: Q-Line
• Trip Type: LI/Non-Interchangeable Thermal Magnetic
• Wire Size: 6 to 1/0 AWG (Copper), 4 to 1/0 AWG (Aluminum)
• Dimensions: 2-3/8 inches L x 3 inches W x 3-9/32 inches H
• Mounting Type: Bolt-On
• Temperature Rating: 60 to 75 degrees Celsius
