GE THQB32090 THQB Molded Case Miniature Supplementary Protector, 240 VAC, 90 Amp, 10 kA Interrupt, 3 Poles

Product Description

GE THQB32090 is a type THQB molded case miniature supplementary protector with a voltage rating of two hundred forty volts AC and an amperage rating of ninety amps. This device features thermal magnetic trip functionality and is designed for residential and commercial applications.

• Rated voltage of two hundred forty volts AC
• 90 amps maximum current rating
• 10 kA interrupt rating for overcurrent protection

Product Highlights

This supplementary protector is suitable for use in electrical distribution and control applications, ensuring reliable operation in various settings.

Product Information

Standard Information

• Brand: GE
• Manufacturer: ABB Electrification

Technical Specifications

• Type: THQB Molded Case Miniature
• Voltage Rating: 240 VAC
• Amperage Rating: 90 A
• Number of Poles: 3
• Interrupt Rating: 10 kA
• Trip Type: Common/LI/Thermal Magnetic
• Wire Size: 6 to 1/0 AWG, 4 to 1/0 AWG
• Dimensions: 3.28 in H x 3 in W x 2.38 in D
• Temperature Rating: 40 deg C
• Mounting Type: Bolt-On
• Country of Origin: UU
• Compliance: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL File No. E11592, CSA Certified
