GE THQB32050 THQB Miniature Circuit Breaker 120/240 VAC 50 A 10 kA 3 Poles

Product Description

GE THQB32050 is a miniature circuit breaker designed for use in residential and commercial settings. It operates at a voltage of 120/240 VAC with a current rating of fifty amps and has an interrupt rating of 10 kA. This device includes three poles and features a non-interchangeable thermal magnetic trip.

• Standard continuous current rated
• Fixed long time and instantaneous trip functions
• Wire range from eight to three AWG copper or aluminum

Product Highlights

Compact design suited for various applications, the THQB32050 provides reliable protection against overloads and faults.

Product Information

Standard Information

• Brand: GE
• Manufacturer: ABB Electrification

Technical Specifications

• Amperage Rating: 50 A
• Voltage Rating: 120/240 VAC
• Interrupt Rating: 10 kA
• Number of Poles: 3
• Frame: THQB
• Trip Type: LI/Non-Interchangeable Thermal Magnetic
• Wire Size: 8 to 3 AWG
• Dimensions: 2-3/8 in L x 3 in W x 3-9/32 in H
• Temperature Rating: 60 to 75 degrees Celsius
• Mounting Type: Bolt-On
