GE THQB32015 THQB Miniature Circuit Breaker 120/240 VAC 15 Amp 10 kAIC 3 Poles

Product Description

The GE THQB32015 is a miniature circuit breaker designed for use in 120/240 VAC electrical systems. This unit has a rating of fifteen amps and an interrupt capacity of ten kAIC. The design includes three poles, making it suitable for commercial and residential applications.

• Voltage Rating: 120/240 VAC
• Amperage Rating: 15 A
• Number of Poles: 3

Product Highlights

This circuit breaker provides reliable thermal magnetic trip protection. It features a bolt-on installation suitable for load lug connections. The compact design supports a wide range of wire sizes and ensures application versatility.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part No: THQB32015

Technical Specifications

• Frame: THQB
• Interrupt Rating: 10 kA
• Trip Type: LI/Non-Interchangeable Thermal Magnetic
• Wire Size: 14 to 8 AWG, 12 to 8 AWG
• Dimensions: 3-9/32 in H x 3 in W x 2-3/8 in D
• Temperature Rating: 60 to 75 deg C
• Mounting Type: Bolt-On
• Application: Commercial and Residential
