GE THQB2190 THQB Molded Case Miniature Supplementary Protector 120/240 VAC 90 Amp 10 kAIC 2 Poles

Product Description

GE manufactured the THQB2190, a molded case miniature supplementary protector. This device operates at a voltage of 120/240 VAC with a continuous current rating of 90 amps and an interrupt capacity of 10 kA. This product effectively protects circuits in residential and commercial applications.

• 90 Amp thermal magnetic trip
• Compact footprint for efficient use of space
• UL listed for safety assurance

Product Highlights

This product is suited for electrical distribution and control applications. Designed with a bolt-on mount, it connects easily to load centers and is ideal for applications requiring a common trip feature.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part Number: THQB2190

Technical Specifications

• Type: Molded Case, Fixed Thermal Magnetic, Internal Common Trip
• Voltage Rating: 120/240 VAC
• Amperage Rating: 90 A
• Number of Poles: 2
• Interrupting Rating: 10 kA
• Dimensions: 3-9/32 in H x 2 in W x 2-3/8 in D
• Wire Size: 6 to 1/0 AWG (Copper), 4 to 1/0 AWG (Aluminum)
• Mounting Type: Bolt-On
• Temperature Rating: 60 to 75 deg C
